This document defines the syntax and semantics of a file format for the 3D visualization and interrogation of lightweight geometry and product manufacturing information derived from CAD systems, using visualization software tools that do not need the full capability of a CAD system.

u000b

This document has been adopted as a 3D visualization capability in addition to the ISO 10303 series.

u000b

The ISO 10303 series are the ISO standards adopted for the engineering data exchange, sharing and long-term archiving of product definition information throughout the product lifecycle.

u000b

In this document 3D visualization is defined as the visual presentation on a screen or another media of graphical and textual 3-dimensional representations of a set of data representing an object, information or results of a computational process in order to enable decision process by a human looking at the data visualized in a medium.

u000b

The ISO 14306 file format specification for 3D visualization includes data descriptions that can represent the following data:

u000bu000bfacet information (triangles), stored with geometry compression techniques;u000bvisual attributes such as lights, textures and materials;u000bproduct manufacturing information (PMI);u000bboundary representation (b-rep) solid model shape representation and associated metadata;u000bconfiguration representations; andu000bdelivery methods such as asynchronous streaming of content.u000bu000b

The file format specification for 3D visualization does not specify the implementation of, or definition of a run-time architecture for viewing and/or processing ISO 14306 data.

Product Details

Published:

04/01/2026

File Size:

1 file , 72 MB

Note:

This product is restricted and cannot be purchased in the following countries Ukraine, Russia, Belarus
